MnZn Power Ferrite Material
Home >> Products >> MnZn Power Ferrite Material
|
型号 |
尺寸 |
|||||||
|
A |
Bmin |
C1 |
C2 |
D |
Emin |
F |
H |
|
|
EPC13 |
13.3±0.30 |
10.5 |
5.5±0.2 |
2.00±0.2 |
6.8±0.2 |
8.3 |
4.6±0.2 |
4.75±0.2 |
|
EPC14 |
13.5±0.30 |
11.0 |
5.5±0.2 |
2.00±0.2 |
6.8±0.2 |
9.0 |
4.6±0.2 |
4.75±0.2 |
|
EPC27 |
27.1±0.50 |
21.6 |
13.0±0.3 |
4.00±0.1 |
16.0±0.2 |
18.5 |
8.0±0.2 |
12.00±0.3 |
|
EPC39 |
39.6±0.50 |
31.0 |
17.8±0.2 |
9.7±0.2 |
19.7±0.2 |
25.0 |
15.7±3 |
14.2±0.2 |
|
EPC42 |
42.0±0.80 |
33.5 |
16.7±0.3 |
7.30±0.3 |
21.6±0.3 |
26.2 |
14.9±0.3 |
16.20±0.3 |
|
EPC46 |
46.5±0.80 |
36.20 |
20.85±0.3 |
11.90±0.3 |
22.50±0.3 |
29.1 |
19.4±0.3 |
15.5±0.3 |
|
型号 |
有效参数 |
重量(g) |
AL值 AL(nH/N²) |
||||
|
C1(mm-1) |
Le(mm) |
Ae(mm2) |
Ve(mm3) |
HCP4 |
HC-10 |
||
|
EPC13 |
2.46 |
30.6 |
12.5 |
382 |
2.5 |
|
3000±25% |
|
EPC14 |
2.46 |
30.6 |
12.5 |
382 |
2.5 |
870±25% |
|
|
EPC27 |
1.34 |
73.1 |
54.6 |
3995 |
19.5 |
1540±25% |
|
|
EPC39 |
0.58 |
90.9 |
155.7 |
14158 |
79.0 |
5000±30% |
|
|
EPC42 |
0.92 |
102.0 |
110.0 |
16048 |
76.0 |
2800±25% |
|
|
EPC46 |
0.52 |
115.2 |
217.6 |
26806 |
134.0 |
5500±25% |
|
